Introducing Connector Kings' flagship product, the ultimate solution for irrigation systems and other applications. Perfect for 2-wire decoder systems or multiwire connections.
Engineered for reliability and durability, this connector ensures secure and seamless connections in underground installations.
Designed to withstand harsh environmental conditions, it provides long-lasting performance and resistance to corrosion by utilizing Connector Kings proprietary XR compound that does not wash away like most animal based greases.
With its user-friendly design, installation is quick and hassle-free, making it ideal for irrigation professionals and water management agencies alike.
Trust Connector Kings' 3 Wire Direct Burial Connector to deliver unmatched reliability and efficiency in your irrigation systems.
• Zero failure rate after 35 years in use.
• Works great for low voltage lighting.
• Pre-filled with XR compound
• Works with wire nuts, crimp sleeves, UY, and UR connectors.
• UV resistant
Technical Specs:
Temperature Rating: 195F Sealant Temperature
Range: -50F to 480F
Maximum Voltage: 30V
Size: 2 1⁄2” x 3⁄4”
Wire Combinations: CU/CU
Minimum: 9 conductors of # 20awg
Maximum: 3 conductors of # 10awg
SA102 CONNECTOR CROSS REFERENCE:
King models: king1, 2, 3, 4, 5, 6, 7, &8
3M models: DBY, DBR, 314, 316, Scotchlok 3570 Resin Pak
